Electrical Characteristics Specifications

·         Power

·         1.AC90 ~ 260V, 50/60HZ

·         2. Built-in rechargeable battery DC18V 3.4A

·         3. External Battery DC 18V 4A above

·         Output Power RMS 60W

·         Frequency Response 50HZ ~ 20KHZ +.-3db

·         Current consumption 45W

·         Charging time 10 to 12 hours

·         Input signal

·         1 wired microphone MIC1/MIC2/MIC3 (-54db 600 ohm)

·         2 wireless microphone VOL.1/VOL.2

·         3. Auxiliary input-20dbV 500K Ohm

·         Output Signal : 0db 600 ohms / PA SYSTEM 0db 600 ohms

·         External Speaker

·         8 ohm to 16 ohm 40W or more, can automatically switch the internal speaker / external speaker / simultaneous operation of the internal and external speakers

·         Internal speaker 20cm 80W / 4 ohms

·         Material ABS resin molding

·         Size 423 * 266 * 242m / m

·         Weight 9.2KG (with 18V/3.4A rechargeable batteries)

Receiver integrated features

·         Receiving frequency VHF 160MHZ ~ 270MHZ

·         Receiving mode superheterodyne

·         Receiver Sensitivity 10db MV S / N ratio more than 60db

·         Harmonic interference ratio more than 80db

·         Frequency Stability at ± 0.005% or less

·         Dynamic range than 100db

·         S / N ratio more than 95db

Frequency Response 50HZ ~ 20KHZ ± 3db

Wireless Microphones

·         Emission frequency VHF 160MHZ ~ 270MHZ

·         Microphone 1 single directional lavalier condenser microphone / 2 Handheld Dynamic Microphone

·         Transmit power 35MW

·         Sub-harmonics below the carrier more than 50db

·         Current consumption 10mA or less

Battery voltage DC 9V (006P)
