E3ISPM Series C-mount USB3.0 CMOS Camera with Hardware ISP and Video Pipeline



E3ISPM adopt SONY Exmor CMOS sensor as the image-picking device and USB3.0 is used as the transfer interface. E3ISPM hardware resolutions range from 1.5M to 45M and come with the integrated CNC aluminum alloy compact housing.

E3ISPM integrated with 12 bit Ultra-fine Hardware Image Signal Processor Video Pipline(Ultra-fine TM Hardware ISP/Video Pipeline) for Demosaic, Adjustments, Automatic Exposition, Gain Adjustment, One Push White Balance, Chrominance Adjustment, Saturation Adjustment, Gamma Correction, Luminance Adjustment, Contrast Adjustment, Bayer and finally form RAW data for 8/12 bit output. This will move the heavier burden of the processing from the PC to the Ultra-fineTM Hardware ISP/Video Pipeline and greatly accelerating the processing speed.

E3ISPM comes with advanced video & image processing application ToupView; Providing Windows/Linux/macOS/Android multiple platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc);

The E3ISPMcan be widely used in bright field light environment and microscope image capture and analysis with higher frame rate.

E3ISPMseries adopt SONY Exmor CMOS sensor as the image-picking device and USB3.0 is used as the transfer interface.

E3ISPMseries hardware resolutions range from 1.5M to 45M and come with the integrated CNC aluminum alloy compact housing.

  • SONY Exmor Back-illuminated CMOS sensor with USB3.0 interface;
  • Real-time 8/12/14/16bit depth switch(depending on sensor);
  • Super high sensitivity up to 2350mV(IMX385);
  • Ultra low noise and low power dissipation;
  • With hardware resolution among1.5M to 45M;
  • Rolling Shutter or Global Shutter; Standard C-Mount camera; CNC aluminum alloy housing;
  • With advanced video & image processing application ToupView;
  • Ultra-fine Color hardware Color Enginne ensuring high frame rates(Up to 15 frames for 20M Resolution);
  • Windows/Linux/macOS/Android multiple platform SDK;
