OPTIKA Series B-380 Microscope

OPTIKA Microscope Trinocular Objectives PLAN PH illumination X-LED³ Model B-383PH

Head: Trinocular, 30° inclined, 360°rotating
Eyepiece: Wide Field 10X/20 mm
Objectives: PLAN 4x, 10xPh, 40xPh, 100xPh (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 160x140mm, moving range 78x54mm
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Phase condenser (10x/20x, 40x, 100x) with darkfield (dry) and brightfield
Illuminator: X-LED3, with manual brightness control

OPTIKA Microscope Trinocular Objectives PLAN PH illumination X-LED³ Model B-383Phi

Head: Trinocular, 30° inclined, 360°rotating
Eyepiece: Wide Field 10X/20 mm
Objectives: IOS PLAN 10xPh, 20xPh, 40xPh, 100xPh (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 188x150mm, moving range 78x54mm, Rackless in X direction
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Phase condenser (10x/20x, 40x, 100x) with darkfield (dry) and brightfield
Illuminator: X-LED3, with manual brightness control

OPTIKA Microscope Binocular Objectives PLAN illumination X-LED³ Automatic Light Control Model B-382PH-ALC

Head: Binocular 30° inclined
Eyepiece: Wide Field 10X/20 mm
Objectives: PLAN 4x, 10xPh, 40xPh, 100xPh (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 160x140mm, moving range 78x54mm
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Phase condenser (10x/20x, 40x, 100x) with darkfield (dry) and brightfield
Illuminator: X-LED3, with Automatic Light Control

OPTIKA Microscope Binocular Objectives PLAN PH illumination X-LED³ Automatic Light Control Model B-382PHi-ALC

Head: Binocular 30° inclined
Eyepiece: Wide Field 10X/20 mm
Objectives: IOS PLAN 10xPh, 20xPh, 40xPh, 100xPh (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 188x150mm, moving range 78x54mm, Rackless in X direction
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Phase condenser (10x/20x, 40x, 100x) with darkfield (dry) and brightfield
Illuminator: X-LED3, with Automatic Light Control

OPTIKA Microscope Trinocular Objectives E-PLAN illumination X-LED³ Model B-383PL

Head: Trinocular,30° inclined,360°rotating
Eyepiece: Wide Field 10X/20 mm
Objectives: E-PLAN 4x, 10x, 40x, 100x (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 160x140mm, moving range 78x54mm
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Abbe N.A. 1.25, with iris diaphragm, focusable and centerable.
Illuminator: X-LED3, with manual brightness control

OPTIKA Microscope Trinocular Objectives E-PLAN illumination X-LED³ Model B-383PLi

Head: Trinocular, 30° inclined, 360°rotating
Eyepiece: Wide Field 10X/20 mm
Objectives: IOS E-PLAN 4x, 10x, 40x, 100x (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 188x150mm, moving range 78x54mm, Rackless in X direction
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Abbe N.A. 1.25, with iris diaphragm, focusable and centerable.
Illuminator: X-LED3, with manual brightness control

OPTIKA Microscope Binocular Objectives E-PLAN illumination X-LED³ Automatic Light Control Model B-382PL-ALC

Head: Binocular 360°rotating 30° inclined
Eyepieces : Wide Field 10X/20 mm
Objectives: E-PLAN 4x, 10x, 40x, 100x (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 160x140mm, moving range 78x54mm
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Abbe condenser, sliding-in, N.A. 1.25 with centering system
Illuminator: X-LED³, with Automatic Light Control
Power supply: External power supply: Input 100-240Vac, 50-60Hz. Output 6Vdc 1A

OPTIKA Microscope Binocular Objectives E-PLAN illumination X-LED³ Automatic Light Control Model B-382PLi-ALC

Head: Binocular 360°rotating 30° inclined
Eyepieces: Wide Field 10X/20 mm
Objectives: IOS E-PLAN 4x, 10x, 40x, 100x (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 188x150mm, moving range 78x54mm, Belt-drive in X direction
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Abbe condenser, sliding-in, N.A. 1.25 with centering system
Illuminator: X-LED³, with Automatic Light Control
Power supply: External power supply: Input 100-240Vac, 50-60Hz. Output 6Vdc 1A

OPTIKA Microscope Trinocular Objectives E-PLAN illumination X-LED³ Model B-383DK

Head: Trinocular, 30° inclined, 360°rotating
Eyepiece: Wide Field 10X/20 mm
Objectives: E-PLAN 4x, 10x, 40x PLAN 100x (oil, with iris diaphragm)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 160x140mm, moving range 78x54mm
Focusing: Coaxial coarse and fine focusing with limit stop

Condenser: Abbe N.A. 1.25, with iris diaphragm, focusable and centerable.Darkfield N.A. 1.36 with built-in X-LED3.
Illuminator: X-LED3, with manual brightness control
