B-150POL-B Binocular polarizing microscope, 400x, round stage
Model: B-150POL-B
Head: Binocular
Eyepiece: WF10x/18mm
Objectives: DIN Achromatic 4X/10X/40X
Stage: Rotatable stage, 120mm diameter
Focusing: Coaxial coarse and fine focusing mechanism with limit stop
Condenser: 1.2 N.A. with diaphragm
Illuminator: 1W LED with external power supply.
Rotatable swing-out polarizer, slide-out analyzer.
B-157 Binocular microscope, 600x, double layer stage
Model: B-157
Head: Binocular
Eyepiece: WF10x/18mm
Objectives: Achromatic 4X/10X/40X/60X
Stage: Mechanical stage, 125x116mm with specimen holder
Focusing: Coaxial coarse and fine focusing mechanism with limit stop
Condenser: 1.2 N.A. with diaphragm
Illuminator: 1W LED with external power supply
B-159 Binocular microscope, 1000x, double layer stage
Model: B-159
Head: Binocular
Eyepiece: WF10x/18mm
Objectives: DIN Achromatic 4X/10X/40X/100X
Stage: Mechanical stage, 125x116mm with specimen holder
Focusing: Coaxial coarse and fine focusing mechanism with limit stop
Condenser: 1.2 N.A. with diaphragm
Illuminator: 1W LED with external power supply
B-150POL-BR Binocular polarizing microscope, 400x, round stage.
Model: B-150POL-BR
Head: Binocular
Eyepiece: WF10x/18mm
Objectives:DIN Achromatic 4x/10X/40X
Stage: Rotatable stage 120mm diameter
Condenser: 1.2 N.A. with diaphragm
Focusing: Coaxial coarse and fine focusing mechanism with limit stop
Illuminator: 1W LED with rechargeable battery. Rotatable swing-out polarizer, slide-out analyzer.
B-157R Binocular microscope 600x, double layer stage, with rechargeable batteries
Model: B-157R
Head: Binocular
Eyepiece: WF10x/18mm
Objectives: Achromatic 4X/10X/40X/60X
Stage: Mechanical stage, 125x116mm with specimen holder
Focusing: Coaxial coarse and fine focusing mechanism with limit stop
Condenser: 1.2 N.A. with diaphragm
Illuminator: 1W LED with external power supply
Power supply: Input Voltage: 100-240Vac / 50-60Hz
Output: 5Vdc 500mA (B-150R model: 6Vdc 2,5A)
Internal NiMH rechargeable battery (B-150R models only)
B-192s Binocular with achromatic objectives
Model: B-192s
Head: Binocular, 360° rotating, 30° inclined with adjustable interpupillary distance and dioptric compensation
Eyepieces: Wide Field 10x/18mm
Revolving: nosepiece Quadruple, reversed
Objectives: DIN Achromatic 4x/0.10, 10x/0.25, 40x/0.65, 60x/0.85
Stage: Double layer, 125x115 mm with X-Y 70x30mm moving range
Focusing: Coaxial coarse and fine focusing
Illuminator: X-LED2 system with adjustable intensity
Condenser: 1,25 N.A. Abbe type with adjustable height and iris diaphragm
Power supply: 100-240 Vac 50-60 Hz external power unit 7,5 Vdc output
Special version of the B-192 model, fitted with 60x/0.85 objective instead of the 100x/1.25 objective
B-192 Binocular with achromatic objectives
Model: B-192
Head: Binocular, 360° rotating, 30° inclined with adjustable interpupillary distance and dioptric compensation
Eyepieces: Wide Field 10x/18mm
Revolving: nosepiece Quadruple, reversed
Objectives: DIN Achromatic 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25
Stage: Double layer, 125x115 mm with X-Y 70x30mm moving range
Focusing: Coaxial coarse and fine focusing
Illuminator: X-LED2 system with adjustable intensity
Condenser: 1,25 N.A. Abbe type with adjustable height and iris diaphragm
Power supply: 100-240 Vac 50-60 Hz external power unit 7,5 Vdc output
B-292 Binocular microscope 1000x, E-PLAN objectives, belt drive stage, X-LED illumination
Model: B-292
Head: Binocular, 360° rotating, 30° inclined.
Eyepiece: Wide Field 10x/20mm
Nosepiece: Quadruple, reversed
Objectives: DIN E-PLAN Achromatic 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25
Stage: Double layer, 150x133 mm with X-Y 75x50mm moving range
Focusing: Coaxial coarse and fine focusing
Illuminator: X-LED3 system with adjustable intensity
Condenser: Sliding-in, 1.25 N.A. Abbe type with adjustable height and iris diaphragm
Power supply: 100-240 Vac 50-60 Hz external power adapter 6Vdc output.
B-150POL-BR Binocular polarizing microscope, 400x, round stage.
Model: B-150POL-BR
Head: Binocular
Eyepiece: WF10x/18mm
Objectives: DIN Achromatic 4x/10X/40X
Stage: Rotatable stage 120mm diameter
Condenser: 1.2 N.A. with diaphragm
Focusing: Coaxial coarse and fine focusing mechanism with limit stop
Illuminator: 1W LED with rechargeable battery. Rotatable swing-out polarizer, slide-out analyzer.
B-157R Binocular microscope 600x, double layer stage, with rechargeable batteries
Model: B-157R
Head: Binocular
Eyepiece: WF10x/18mm
Objectives: Achromatic 4X/10X/40X/60X
Stage: Mechanical stage, 125x116mm with specimen holder
Focusing: Coaxial coarse and fine focusing mechanism with limit stop
Condenser: 1.2 N.A. with diaphragm
Illuminator: 1W LED with external power supply
Power supply: Input Voltage: 100-240Vac / 50-60Hz
Output: 5Vdc 500mA (B-150R model: 6Vdc 2,5A)
Internal NiMH rechargeable battery (B-150R models only)
B-382PH-ALC Binocular microscope, phase contrast, Automatic Light Control
Model: B-382PH-ALC
Head: Binocular 360°rotating 30° inclined
Eyepieces: Wide Field 10X/20 mm
Objectives: PLAN 4x, 10xPh, 40xPh, 100xPh (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 160x140mm, moving range 78x54mm
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Phase condenser (10x/20x, 40x, 100x) with darkfield (dry) and brightfield
Illuminator: X-LED3, with Automatic Light Control
Power supply: External power supply: Input 100-240Vac, 50-60Hz. Output 6Vdc 1A
B-382PHi-ALC Binocular microscope, phase contrast, IOS objectives, belt drive stage, Automatic Light Control
Model: B-382PHi-ALC
Head: Binocular 360°rotating 30° inclined
Eyepieces: Wide Field 10X/20 mm
Objectives: IOS PLAN 10xPh, 20xPh, 40xPh, 100xPh (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 216x150mm, moving range 78x54mm, Belt-drive in X direction
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Phase condenser (10x/20x, 40x, 100x) with darkfield (dry) and brightfield
Illuminator: X-LED3, with Automatic Light Control
Power supply: External power supply: Input 100-240Vac, 50-60Hz. Output 6Vdc 1A
B-382PL-ALC Binocular microscope E-PL, with Automatic Light Control
Model: B-382PL-ALC
Head: Binocular 360°rotating 30° inclined
Eyepieces : Wide Field 10X/20 mm
Objectives: E-PLAN 4x, 10x, 40x, 100x (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 160x140mm, moving range 78x54mm
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Abbe condenser, sliding-in, N.A. 1.25 with centering system
Illuminator: X-LED3, with Automatic Light Control
Power supply: External power supply: Input 100-240Vac, 50-60Hz. Output 6Vdc 1A
B-382PLi-ALC Binocular microscope E-PL IOS belt drive stage, with Automatic Light Control
Model: B-382PLi-ALC
Head: Binocular 360°rotating 30° inclined
Eyepieces: Wide Field 10X/20 mm
Objectives: IOS E-PLAN 4x, 10x, 40x, 100x (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 216x150mm, moving range 78x54mm, Belt-drive in X direction
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Abbe condenser, sliding-in, N.A. 1.25 with centering system
Illuminator: X-LED3, with Automatic Light Control
Power supply: External power supply: Input 100-240Vac, 50-60Hz. Output 6Vdc 1A
B-159R Binocular microscope 1000x with rechargeable batteries
Model: B-159R
Head: Binocular
Eyepiece: WF10x/18mm
Objectives: DIN Achromatic 4X/10X/40X/100X
Stage: Mechanical stage, 125x116mm with specimen holder
Focusing: Coaxial coarse and fine focusing mechanism with limit stop
Condenser: 1.2 N.A. with diaphragm
Illuminator: 1W LED with external power supply
Power supply: Input Voltage: 100-240Vac / 50-60Hz
Output: 5Vdc 500mA (B-150R model: 6Vdc 2,5A)
Internal NiMH rechargeable battery (B-150R models only)
B-383PH Trinocular microscope, phase contrast
Model: B-383PH
Head: Trinocular 360°rotating 30° inclined
Eyepieces: Wide Field 10X/20 mm
