Trinocular discussion microscope
B-1000Ti-10 Trinocular discussion microscope, 10 heads.
Model: B-1000Ti-10
Head: Trinocular observation head (main head) and binocular (discussion heads), inclined 30° and rotatable 360°.
Diopter adjustment on left eyepiece.
Interpupillary adjustment 55-75 mm.
M-1163: Multi-viewing device (10 simultaneous observers).
Discussion LED pointer (arrow) under the main head.
Illumination: Light source type X-LED 14W with white LED; light intensity control using a knob on left side of the frame.
LED power: 14W (comparable to a 150W halogen bulb).
Color temperature: 6300K
LED average lifetime approx.: 50.000h.
External power supply: Input 100-240Vac 50-60Hz / Output 6Vdc 5A.
Max power required: 22W
Observation Modes: Brightfield
Focusing: Coaxial coarse and fine focusing mechanism (graduated, 0.002mm) with upper stop, to prevent the contact between objective and specimen.
Adjustable tension of coarse focusing knob.
Stage: See catalog for available stages.
Nosepiece: Sextuple revolving nosepiece, rotation on ball bearings. (see M-1042 or M-1043)
Eyepieces: Widefield eyepieces WF10X with field number 22 (on main head) and field number 20 (on discussion heads).
Objectives: Infinity corrected optical system IOS (Infinity Optical System).
See catalog for available objective sets.
Condenser: Swing-out type, N.A.0,9 (M-1150) or N.A.1,2 (M-1152) with centering system.
B-1000Ti-2 Trinocular discussion microscope, 2 heads.
Model: B-1000Ti-2
Head: Trinocular observation head (main head) and binocular (discussion heads), inclined 30° and rotatable 360°.
Diopter adjustment on left eyepiece.
Interpupillary adjustment 55-75 mm.
M-1160: Multi-viewing device (2 simultaneous observers).
Discussion LED pointer (arrow) under the main head.
Illumination: Light source type X-LED8 with white LED; light intensity control using a knob on left side of the frame.
LED power: 8W (comparable to a 100W halogen bulb).
Color temperature: 6300K
LED average lifetime approx.: 50.000h.
External power supply: Input 100-240Vac 50-60Hz / Output 6Vdc 2,5A.
Max power required: 13W
Observation Modes: Brightfield
Focusing: Coaxial coarse and fine focusing mechanism (graduated, 0.002mm) with upper stop, to prevent the contact between objective and specimen.
Adjustable tension of coarse focusing knob.
Stage: See catalog for available stages.
Nosepiece: Sextuple revolving nosepiece, rotation on ball bearings. (see M-1042 or M-1043)
Eyepieces: Widefield eyepieces WF10X with field number 22 (on main head) and field number 20 (on discussion heads).
Objectives: Infinity corrected optical system IOS (Infinity Optical System).
See catalog for available objective sets.
Condenser: Swing-out type, N.A.0,9 (M-1150) or N.A.1,2 (M-1152) with centering system.
B-1000Ti-3 Trinocular discussion microscope, 3 heads.
Model: B-1000Ti-3
Head: Trinocular observation head (main head) and binocular (discussion heads), inclined 30° and rotatable 360°.
Diopter adjustment on left eyepiece.
Interpupillary adjustment 55-75 mm.
M-1161: Multi-viewing device (3 simultaneous observers).
Discussion LED pointer (arrow) under the main head.
Illumination: Light source type X-LED8 with white LED; light intensity control using a knob on left side of the frame.
LED power: 8W (comparable to a 100W halogen bulb).
Color temperature: 6300K
LED average lifetime approx.: 50.000h.
External power supply: Input 100-240Vac 50-60Hz / Output 6Vdc 2,5A
Max power required: 13W
Observation Modes: Brightfield
Focusing: Coaxial coarse and fine focusing mechanism (graduated, 0.002mm) with upper stop, to prevent the contact between objective and specimen.
Adjustable tension of coarse focusing knob.
Stage: See catalog for available stages.
Nosepiece: Sextuple revolving nosepiece, rotation on ball bearings. (see M-1042 or M-1043)
Eyepieces: Widefield eyepieces WF10X with field number 22 (on main head) and field number 20 (on discussion heads).
Objectives: Infinity corrected optical system IOS (Infinity Optical System).
See catalog for available objective sets.
Condenser: Swing-out type, N.A.0,9 (M-1150) or N.A.1,2 (M-1152) with centering system.
B-1000Ti-5 Trinocular discussion microscope, 5 heads.
Model: B-1000Ti-5
Head: Trinocular observation head (main head) and binocular (discussion heads), inclined 30° and rotatable 360°.
Diopter adjustment on left eyepiece.
Interpupillary adjustment 55-75 mm.
M-1162: Multi-viewing device (5 simultaneous observers).
Discussion LED pointer (arrow) under the main head.
Illumination: Light source type X-LED8 with white LED; light intensity control using a knob on left side of the frame.
LED power: 8W (comparable to a 100W halogen bulb).
Color temperature: 6300K
LED average lifetime approx.: 50.000h.
External power supply: Input 100-240Vac 50-60Hz / Output 6Vdc 2,5A.
Max power required: 13W
Observation Modes: Brightfield
Focusing: Coaxial coarse and fine focusing mechanism (graduated, 0.002mm) with upper stop, to prevent the contact between objective and specimen.
Adjustable tension of coarse focusing knob.
Stage: See catalog for available stages.
Nosepiece: Sextuple revolving nosepiece, rotation on ball bearings. (see M-1042 or M-1043)
Eyepieces: Widefield eyepieces WF10X with field number 22 (on main head) and field number 20 (on discussion heads).
Objectives: Infinity corrected optical system IOS (Infinity Optical System).
See catalog for available objective sets.
Condenser: Swing-out type, N.A.0,9 (M-1150) or N.A.1,2 (M-1152) with centering system.
B-1000Ti-10 Trinocular discussion microscope, 10 heads.
Model: B-1000Ti-10
Head: Trinocular observation head (main head) and binocular (discussion heads), inclined 30° and rotatable 360°.
Diopter adjustment on left eyepiece.
Interpupillary adjustment 55-75 mm.
M-1163: Multi-viewing device (10 simultaneous observers).
Discussion LED pointer (arrow) under the main head.
Illumination: Light source type X-LED 14W with white LED; light intensity control using a knob on left side of the frame.
LED power: 14W (comparable to a 150W halogen bulb).
Color temperature: 6300K
LED average lifetime approx.: 50.000h.
External power supply: Input 100-240Vac 50-60Hz / Output 6Vdc 5A.
Max power required: 22W
Observation Modes: Brightfield
Focusing: Coaxial coarse and fine focusing mechanism (graduated, 0.002mm) with upper stop, to prevent the contact between objective and specimen.
Adjustable tension of coarse focusing knob.
Stage: See catalog for available stages.
Nosepiece: Sextuple revolving nosepiece, rotation on ball bearings. (see M-1042 or M-1043)
Eyepieces: Widefield eyepieces WF10X with field number 22 (on main head) and field number 20 (on discussion heads).
Objectives: Infinity corrected optical system IOS (Infinity Optical System).
See catalog for available objective sets.
Condenser: Swing-out type, N.A.0,9 (M-1150) or N.A.1,2 (M-1152) with centering system.
B-1000Ti-2 Trinocular discussion microscope, 2 heads.
Model: B-1000Ti-2
Head: Trinocular observation head (main head) and binocular (discussion heads), inclined 30° and rotatable 360°.
Diopter adjustment on left eyepiece.
Interpupillary adjustment 55-75 mm.
M-1160: Multi-viewing device (2 simultaneous observers).
Discussion LED pointer (arrow) under the main head.
Illumination: Light source type X-LED8 with white LED; light intensity control using a knob on left side of the frame.
LED power: 8W (comparable to a 100W halogen bulb).
Color temperature: 6300K
LED average lifetime approx.: 50.000h.
External power supply: Input 100-240Vac 50-60Hz / Output 6Vdc 2,5A.
Max power required: 13W
Observation Modes: Brightfield
Focusing: Coaxial coarse and fine focusing mechanism (graduated, 0.002mm) with upper stop, to prevent the contact between objective and specimen.
Adjustable tension of coarse focusing knob.
Stage: See catalog for available stages.
Nosepiece: Sextuple revolving nosepiece, rotation on ball bearings. (see M-1042 or M-1043)
Eyepieces: Widefield eyepieces WF10X with field number 22 (on main head) and field number 20 (on discussion heads).
Objectives: Infinity corrected optical system IOS (Infinity Optical System).
See catalog for available objective sets.
Condenser: Swing-out type, N.A.0,9 (M-1150) or N.A.1,2 (M-1152) with centering system.
B-1000Ti-3 Trinocular discussion microscope, 3 heads.
Model: B-1000Ti-3
Head: Trinocular observation head (main head) and binocular (discussion heads), inclined 30° and rotatable 360°.
Diopter adjustment on left eyepiece.
Interpupillary adjustment 55-75 mm.
M-1161: Multi-viewing device (3 simultaneous observers).
Discussion LED pointer (arrow) under the main head.
Illumination: Light source type X-LED8 with white LED; light intensity control using a knob on left side of the frame.
LED power: 8W (comparable to a 100W halogen bulb).
Color temperature: 6300K
LED average lifetime approx.: 50.000h.
External power supply: Input 100-240Vac 50-60Hz / Output 6Vdc 2,5A
Max power required: 13W
Observation Modes: Brightfield
Focusing: Coaxial coarse and fine focusing mechanism (graduated, 0.002mm) with upper stop, to prevent the contact between objective and specimen.
Adjustable tension of coarse focusing knob.
Stage: See catalog for available stages.
Nosepiece: Sextuple revolving nosepiece, rotation on ball bearings. (see M-1042 or M-1043)
Eyepieces: Widefield eyepieces WF10X with field number 22 (on main head) and field number 20 (on discussion heads).
Objectives: Infinity corrected optical system IOS (Infinity Optical System).
See catalog for available objective sets.
Condenser: Swing-out type, N.A.0,9 (M-1150) or N.A.1,2 (M-1152) with centering system.
B-1000Ti-5 Trinocular discussion microscope, 5 heads.
Model: B-1000Ti-5
Head: Trinocular observation head (main head) and binocular (discussion heads), inclined 30° and rotatable 360°.
Diopter adjustment on left eyepiece.
Interpupillary adjustment 55-75 mm.
M-1162: Multi-viewing device (5 simultaneous observers).
Discussion LED pointer (arrow) under the main head.
Illumination: Light source type X-LED8 with white LED; light intensity control using a knob on left side of the frame.
LED power: 8W (comparable to a 100W halogen bulb).
Color temperature: 6300K
LED average lifetime approx.: 50.000h.
External power supply: Input 100-240Vac 50-60Hz / Output 6Vdc 2,5A.
Max power required: 13W
Observation Modes: Brightfield
Focusing: Coaxial coarse and fine focusing mechanism (graduated, 0.002mm) with upper stop, to prevent the contact between objective and specimen.
Adjustable tension of coarse focusing knob.
Stage: See catalog for available stages.
Nosepiece: Sextuple revolving nosepiece, rotation on ball bearings. (see M-1042 or M-1043)
Eyepieces: Widefield eyepieces WF10X with field number 22 (on main head) and field number 20 (on discussion heads).
Objectives: Infinity corrected optical system IOS (Infinity Optical System).
See catalog for available objective sets.
Condenser: Swing-out type, N.A.0,9 (M-1150) or N.A.1,2 (M-1152) with centering system.
B-500ASB Trinocular microscope, Plan objectives 4x, 10x, 40x, 40xPh, 100x, X-LED illumination, Walton & Beckett 12,5x
Model: B-500ASB
Optical System: InfiniFix
Head: Trinocular 360° rotating 30° inclined
Eyepiece; 1 pair: 12,5X Walton-Beckett eyepieces.
1 pair: Widefield 10x/22 mm eyepieces
Objectives: Planachromatic 4x, 10x, 40x, 40xPH, 100x (oil)
Nosepiece: Quintuple reversed
Stage: 2-layer mechanical sliding stage, 175x145 mm
Focusing: Coaxial coarse and fine control knobs
Condenser: - PH condenser 1,25 N.A. for 40XPH.
- Brightfield swing-out 1,2 N.A.
- Both with centering system.
Illuminator: photoscience X-LED3 illuminator.
B-500Tsp Trinocular microscope, Semi-plan objectives 4x, 10x, 40x, 100x, halogen illumination
Model: B-500Tsp
Optical System: InfiniFix
Head: Trinocular 360°rotating 30° inclined
Eyepiece: Wide Field 10X / 22 mm
Objectives: S-planachromatic 4x, 10x, 40x, 100x (oil)
Revolver: Quintuple reversed
Stage: Double layer with mechanical sliding stage, 175x145 mm
Focusing: Coaxial coarse and fine control knobs
Condenser: Swing-out 1.2 N.A., centrable
Illuminator: High efficiency Halogen 20W dichroic bulb.
B-500Tpl Trinocular microscope, Plan objectives 4x, 10x, 40x, 100x, X-LED illumination
Model: B-500Tpl
Optical System: InfiniFix
Head: Trinocular 360°rotating 30° inclined
Eyepiece: Wide Field 10X / 22 mm
Objectives: Plan Achromatic 4x, 10x, 40x, 100x (oil immersion)
Revolver: Quintuple reversed
Stage: Double layer with mechanical sliding stage, 175x145 mm
Focusing: Coaxial coarse and fine control knobs
Condenser: Swing-out 1.2 N.A., centrable
Illuminator: photoscience X-LED™ illuminator.
B-500Ti Trinocular microscope, Plan IOS objectives 4x, 10x, 40x, 100x, X-LED illumination
Model: B-500Ti
Optical System: IOS
Head: Trinocular 360°rotating 30° inclined
Eyepiece: Wide Field 10X / 22 mm
Objectives: Infinity Plan Achro 4x, 10x, 40x, 100x (oil immersion)
Revolver: Quintuple reversed
Stage: Double layer with mechanical sliding stage, 175x145 mm
Focusing: Coaxial coarse and fine control knobs
Condenser: Swing-out 0.90 N.A., centrable
Illuminator: photoscience X-LED™ illuminator.
B-193 Trinocular microscope, 1000x
Model: B-193
Head: Trinocular 360° rotating, 30° inclined with adjustable interpupillary distance and dioptric compensation
Eyepiece: Wide Field 10x/18mm
Revolving: nosepiece Quadruple, reversed
Objectives: DIN Achromatic 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25
Stage: Double layer, 125x115 mm with X-Y 70x30mm moving range
Focusing: Coaxial coarse and fine focusing
Illuminator: X-LED2 system with adjustable intensity
Condenser: 1,25 N.A. Abbe type with adjustable height and iris diaphragm
Power supply: 100-240 Vac 50-60 Hz external power unit 7,5 Vdc output
B-293 Trinocular microscope 1000x, E-PLAN objectives, belt drive stage, X-LED illumination
Model: B-293
Head: Trinocular, 360° rotating, 30° inclined.
Eyepiece: Wide Field 10x/20mm
Nosepiece: Quadruple, reversed
Objectives: DIN E-PLAN Achromatic 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25
Stage: Double layer, 150x133 mm with X-Y 75x50mm moving range
Focusing: Coaxial coarse and fine focusing
Illuminator: X-LED3 system with adjustable intensity
Condenser: Sliding-in, 1.25 N.A. Abbe type with adjustable height and iris diaphragm
Power supply: 100-240 Vac 50-60 Hz external power adapter 6Vdc output.
B-383PL Trinocular microscope, E-PL objectives
Model: B-383PL
Head: Trinocular 360°rotating 30° inclined
Eyepieces: Wide Field 10X/20 mm
Objectives: E-PLAN 4x, 10x, 40x, 100x (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 160x140mm, moving range 78x54mm
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Abbe condenser, sliding-in, N.A. 1.25 with centering system
Illuminator: X-LED3, with manual brightness control
Power supply: External power supply: Input 100-240Vac, 50-60Hz. Output 6Vdc 1A.
B-383PLi Trinocular microscope, E-PL IOS objectives, belt drive stage
Model: B-383PLi
Head: Trinocular 360°rotating 30° inclined
Eyepieces: Wide Field 10X/20 mm
Objectives: IOS E-PLAN 4x, 10x, 40x, 100x (oil)
Nosepiece: Quintuple nosepiece, reversed
Stage: Double layer mechanical sliding stage, 216x150mm, moving range 78x54mm, Belt-drive in X direction
Focusing: Coaxial coarse and fine focusing with limit stop
Condenser: Abbe condenser, sliding-in, N.A. 1.25 with centering system
Illuminator: X-LED3, with manual brightness control
Power supply: External power supply: Input 100-240Vac, 50-60Hz. Output 6Vdc 1A
